MSR Dataloggers

  • Filter
Created on: 29 May 2013

>> Measures Temperature, Humidity, Light, Pressure and Acceleration Simultaneously and 2 or 4 Analog Inputs Also Available >> Stores up to 2 Million (Internal Memory) or 1 Billion (SD Card) Total Readings >> Rechargeable Lithium Polymer Battery >> Data from any number of loggers can be merged synchronously into a single Data Record >> Accelerometer Range of ±15g with -20°C to 65°C Temperature Range >> MSR PC Software Manages Settings and View, Edit, Export Data >> External Temperature, Humidity, Light, Air and Fluid Pressure Sensors Available >> Includes CD Software and USB Cable Multiple Measurement Parameters Available >> Temperature >> Humidity >> Air Pressure (0 to 2000mbar or 0 to 14bar) >> Fluid Pressure (0 to 3000mbar or 0 to 30bar) >> Acceleration >> Light Level >> 2 or 4 Analog Inputs External Sensors Available for Temperature, Humidity, Pressure and LIght (Call 1-603-746-5524 to Order) Included with each MSR145 >> Software CD >> USB Cable NOTE: All External Sensors are Available as a Special Order. Large Quantity Discounts Are Available! All MSR145s are Built...

Created on: 29 May 2013

LCD Miniature Data Logger MSR Electronics Universal Data Logger with 5 Internal Sensor Options and 4 Analog Inputs >> Measures Temperature, Humidity, Light, Air Pressure and Acceleration Simultaneously and Includes 4 Analog Inputs >> LCD Display Shows up to 4 Current Values, Battery Status and Alarm Values >> Stores up to 2 Million Total Readings on Internal Memory >> Rechargeable Lithium Polymer Battery >> Data from any number of loggers can be merged synchronously into a single Data Record >> Accelerometer Range of ±15g with -20°C to 65°C Temperature Range >> MSR PC Software Manages Settings and View, Edit, Export Data >> External Temperature, Humidity, Light and Air Pressure Sensors Available >> Includes CD Software and USB Cable Multiple Measurement Parameters Available >> Temperature >> Humidity >> Air Pressure (0 to 2000mbar or 0 to 14bar) >> Acceleration >> Light Level External Sensors Available for Temperature, Humidity and Pressure

Created on: 29 May 2013

>> 4 Integrated Analogue Inputs Sample up to 1000 per Second >> Stores up to 2 Million Recorded Readings >> 0 to 3.0 Volt Measurement Range for Analog Inputs (Additional Ranges Available: 0 to 20mA, 4 to 20mA, 0.5V to 4.5V, 0 to 5V, 1V to 6V, 0 to 10V, 0 to 12V and 0 to 24V by Special Order) >> Each Analog Input Can Be Replaced with Internal or External Sensor >> Internal Sensors Available for Temp, Humidity, Pressure & 3-Axis Acceleration >> External Sensors Available for Temperature, Humidity & Air Pressure >> USB Interface for Transferring Data to Computer >> Waterproof Version Available >> Anodised Aluminum Case with Rechargeable Lithium Polymer Battery >> Optional Expansion Slot for MicroSD Card to Store 1 Billion Measurements Available >> Includes MSR PC Software to Manage Settings and View, Edit, Export Measured Data

Created on: 29 May 2013

>> Capable of Making 1600 Acceleration (Shock, Vibrations) Measurements per Second in All 3 Axes >> 32 Measurement Values are Recorded Even Before the Event Takes Place >> Measurement Range of ±15g in -20°C to 65°C Temperature Range >> Also Records Temperature, Humidity, Air Pressure, Light and 4 Analog Input Signals >> MSR PC Software Manages Settings and View, Edit, Export Measured Data >> Includes CD Software and USB Cable Additional Measurement Parameters Available >> Temperature >> Humidity >> Pressure (Air) >> Light Level >> Any Analog Input Signal External Sensors (Temperature, Humidity, Pressure and Light) and 4 Analog Inputs Available

Created on: 29 May 2013

MSR Electronics Portable and Expandable Data Logger Capable of Measuring Almost any Analog or Digital Signal The MSR12 Modular Signal Recorder is a practical, portable signal acquisition instrument for measuring, displaying and recording a range of environmental paramters. With its modular and expandable design, plug-in modules are available to record almost any signal. MSR PC Software Manages Settings and View, Edit, Export Measured Data. The Basic MSR12 System includes >> (2) Modules: 3-Axis Accelerometer and PR8 Pressure Modules >> (3) Sensors: Acceleration, Air Pressure, Ambient Temperature >> PC Software >> Mains AC Adapter >> User Manual and Warranty

Created on: 29 May 2013

MSR PC Software Version 5.12.04 with MSR Setup, MSR Reeder, MSR Online and MSR Viewer Software Programs MSR Software Consists of 4 Separate Programs >> MSR Setup: Used to Configure MSR Data Loggers >> MSR Reader: Download Data from Logger to PC >> MSR Online: View Data On-screen and Save Data to PC >> MSR Viewer: Data Viewed on PC in Graph or Table Format MSR Software System Requirements >> Windows 7, Vista, XP, 2000 PC Operating System >> USB Port Software is Included with the Purchase of an MSR Data Logger.
